Radiator

Removal

NOTE: Removal steps in this procedure may contain installation details.

1. Refer to: Engine Cooling System Health and Safety Precautions (100-00 General Information, Description and Operation).


1. Refer to: Charge Air Cooler (CAC) Radiator (303-12A Intake Air Distribution and Filtering - 1.5L EcoBoost (118kW/160PS), Removal and Installation).


1. General Equipment : Hose Clamp Remover/Installer

1. Torque : 5 Nm

1. General Equipment : Hose Clamp Remover/Installer

1. Torque : 6 Nm

1. General Equipment : Hose Clamp Remover/Installer
   Torque : 7 Nm

1. Torque : 6 Nm

Installation

1. To install, reverse the removal procedure.
