412-00 Climate Control System - General Information 2013 - 2014 Fusion
Removal and Installation Procedure revision date: 08/28/2012

Climate Control Housing - Vehicles With: Dual Automatic Temperature Control (DATC)

Removal

NOTE: Removal steps in this procedure may contain installation details.

  1. WARNING: Before beginning any service procedure in this section, refer to Safety Warnings in section 100-00 General Information. Failure to follow this instruction may result in serious personal injury.

    Refer to: Climate Control System Health and Safety Precautions (100-00 General Information, Description and Operation).
  1. Refer to: Instrument Panel (501-12 Instrument Panel and Console, Removal and Installation).
  1. Torque : 15 Nm
  1. Torque : 15 Nm

Installation

  1. To install, reverse the removal procedure.
