Brake Caliper Anchor Plate

Removal

NOTE: Removal steps in this procedure may contain installation details.

1. Refer to: Wheel and Tire (204-04A Wheels and Tires, Removal and Installation).


1. NOTICE: Do not pry in the caliper sight hole to retract the pistons as this can damage the pistons and boots.

   NOTICE: Do not allow the brake caliper and anchor plate assembly to hang from the brake hose or damage to the hose can occur.

   Relocate and support the component.
   Torque : 30 Nm

1. Discard the specified component. Follow local disposal regulations.
   Torque : 150 Nm

Installation

1. NOTICE: Make sure that the brake hose is not twisted when installing the brake caliper or damage to the brake flexible hose may occur.

   To install, reverse the removal procedure.
